Ultrasonic Blade Cut Cookie Machine for Hard Nut Cookie

Technical parameters:

1. Mould spacing 60mm, number of moulds 24:

2. Forming method: ultrasonic blade cutting;

3. Fastest working times: cutting 55 times/min

4. Cookie weight deviation: ±4% (weigh every 5 cookies); qualified rate: 98%

5. Production speed: determined by the length of the production line furnace and baking time

6. Energy requirements: determined according to customer needs (generally 380V/50Hz), total power: about 3-5KW

7. Overall dimensions and weight: (length * width * height) 2250*3050*1950 Weight: about: 3 (T)

Features:

1. This machine is mainly used for forming the dough of high-fat cookies and pastries with granular materials

2. It adopts material pump feeding, precise control, and small deviation of cookie weight;

3. The feeding trough roller, material pump and cutting are driven by servo motors and controlled independently

4. The trough roller speed, material pump feeding speed, cutting speed and other parameters are controlled by touch screen, which is easy to operate

5. The material pump assembly adopts worm gear clamping method, which is convenient for disassembly, cleaning and replacement, and simple operation

6. The cutting mold assembly adopts eccentric wheel clamping, which is convenient for disassembly, cleaning and replacement, and simple operation

7. The cutting assembly adopts cam connecting rod mechanism, which moves smoothly
